MAIN FEATURES
- Support mirror switch
- Tape transfer function
- Waterproof grade IP69K
- With tail tube, magnet mounting
PRODUCT CHARACTERS
| Model Name | VW-FKC100/VW-FKC100M |
| Image Sensor | 1/3’’ CMOS |
| TV System | NTSC/PAL |
| Effective Pixels | 968(H)*488(V) |
| Sensing Area | 4.880mm*3.670mm |
| Sync. System | Internal |
| Resolution | 700 TVL |
| Minimum Illumination | 0.1 Lux (day), 0 Lux (with IR) |
| Microphone | NO |
| IR LED Qty | white light 4pcs |
| Video Output | 1.0 Vp-p/75 Ohm |
| Scanning System | interlace |
| AGC | AUTO |
| Signal to noise ratio | Better than 48dB |
| White balance | AUTO |
| Gamma Consumption | 0.45 |
| Electronic Shutter | AUTO |
| Backlight Compensation | AUTO |
| Power Supply | DC12V |
| Lens | 5.68mm |
| Lens Angle | 53° |
| Current Drain | 70±5mA |
| Operating Temperature | -20℃-70℃, RH 95% Max |
| Storage Temperature | -30℃-80℃, RH 95% Max |
