| Zoom Camera | |
| Resolution | 1920（H）X 1080（V） |
| Communication mode | RS232 |
| Communication protocol | SONY VISCA |
| Interface | 9 Pin |
| CCD | 1/2.9″ CMOS |
| Day & Night | Color/ B&W /Auto |
| Mini Illumination | 0.1Lux |
| Video output | AHD/CVI/TVI/CVBS |
| SNR | ≥50dB（AGC OFF） |
| Lens | |
| IRCUT | Support |
| Relative aperture（F.N） | F1.6～F2.5 |
| FNO./Focal Length | 18X f=6.0mm～96mm |
| FOV | 45°（W）～3.1°（T） |
| Functions | |
| Exposure Mode | Auto |
| AWB | Auto |
| Focus Mode | Auto/Manual |
| Mirror | Support |
| DNR | 3D/2D |
| Contrast | Support |
| Saturation | Support |
| General Specifications | |
| Size | 38.6（W）* 41（H）* 64.6（L） mm |
| Working Temp./Hygro. | ﹣10℃～50℃，10％RH～60％RH |
| Storage Temp./Hygro. | ﹣20℃～60℃，10％RH～80％RH |
| Power | DC 12V±10% |
| Power consumption | 2.5W MAX |
| Weight | 108g |
