MAIN FEATURES
- Perfect structure design, smaller size for installing in limited space;
- High-performance photosensitive chip provides high-definition colors, especially in light environment at night;
- Six layers of all-glass lenses provide true colors display;
- Anti-vibration design and anti-aging spare parts ensure the camera have longer work life and better stability;
- 360-degree waterproof design without dead corners;
- Flexible and adjustable angle design ensures that the camera can see a wider target angle area;
- Multiple lenses are optional, such as, 2.1mm, 2.5mm, 2.8mm . . .
TECHNICAL SPECIFICATIONS
| MODEL: | VW-SL-300 | |
| Sensor | 1/2.9＂CMOS 2053 | |
| System | PAL/NTSC | |
| Effective Pixels | 1920(H)x1080(V) 2.0mp | |
| Night Vision Mode | Full color star light | |
| Minimum illumination | 0.1Lux@(F1.2, AGC ON)，0LUX with IR | |
| IR Distance | 10m | |
| Lens | Default 2.8mm (2.1mm optional); | |
| Shutter | Auto | |
| Backlight Compensation | Auto | |
| S/N ratio | ≥48db | |
| Automatic Gain | Auto | |
| White Balance | Auto | |
| Exposure Method | EE | |
| Intelligent Sense | YES | |
| Gamma Correction | 0.45 | |
| Synchronization Mode | Internal synchronization | |
| Video Output | 1.0VP-P/75Ω | |
| FPS | 25fps / 30fps | |
| Waterproof Level | IP68 | |
| Working Temperature | -20℃~+60℃ | |
| Working Humidity | ≤90% | |
| Power Supply-current | DC12V (±20%) – 80MA | |
