MAIN FEATURES
- Perfect structure design, smaller size for installing in limited space;
- High-performance photosensitive chip provides high-definition colors, especially in light environment at night;
- Six layers of all-glass lenses provide true colors display;
- Anti-vibration design and anti-aging spare parts ensure the camera have longer work life and better stability;
- 360-degree waterproof design without dead corners;
- Flexible and adjustable angle design ensures that the camera can see a wider target angle area;
- Multiple lenses are optional, such as, 2.1mm, 2.8mm . . .
TECHNICAL SPECIFICATIONS
| MODEL: | VW-SL-200 |
| Sensor | 1/2.9＂CMOS 2053 |
| System | PAL/NTSC |
| Effective Pixels | 1920(H)x1080(V), 2.0mp |
| Intensity of illumination | 0.01 Lux (Color); 0.001 Lux F1.2 (B/W) |
| IR Distance | 10m |
| Night Vision Mode | Full color star light |
| Lens | Default 2.8mm (2.1mm optional); |
| Shutter | Auto (1/5s~1/50,000s) |
| Backlight Compensation | Auto |
| S/N ratio | ≥48db |
| Automatic Gain | Auto |
| White Balance | Auto |
| Exposure Method | EE |
| Intelligent Sense | YES |
| Gamma Correction | 0.45 |
| Synchronization Mode | Internal synchronization |
| Video Output | 1.0VP-P/75Ω |
| FPS | 25fps / 30fps |
| Audio | Optional |
| Waterproof Level | IP68 |
| Working Temperature | -20℃~+60℃ |
| Working Humidity | ≤90% |
| Power Supply/Current | DC12V (±20%) / 80mA |
