FEATURES
- Can be used for various commercial vehicles in harsh environment，such as，muck trucks, cargo trucks, passenger cars, etc.
- Can be used as blind spot warning、left and right turn warning.
- Provides a maximum 95dB voice and warning light alarm.
- Alarm can be triggered by signal (5V or above)
- Built-in car-grade high-power horn.
- Built-in 4 high-brightness LED lights, through fog and rain.
- Wide voltage design, DC9V-32V, external body power ACC and DVR power supply.
- With 8 electronic wire connectors, left、right turn and reversing alarm as default, but customizable.
- Stable and reliable, high temperature resistance
- Military level anti-shock performance.
TECHNICAL SPECIFICATIONS
| No. | Item | Parameters | Marks |
| 1 | Speaker’s rated output power | 5W | |
| 2 | Speaker’s maximum output power | 10W | |
| 3 | Speaker input sensitivity | 500mV | |
| 4 | Speaker frequency response range | 200Hz—12KHz | |
| 5 | Total harmonic distortion of speakers | 0.5% | |
| 6 | Speaker signal-to-noise ratio | 80dB | |
| 7 | Horn Hum & Noise | 0.5mV | |
| 8 | Speaker maximum volume | 95dB | Within 1m |
| 9 | Number of lamp beads | 4pcs | |
| 10 | Lamp bead power | 4*1w | |
| 11 | Beam angle | 270° | |
| 12 | Communication Interface | I/O | |
| 13 | Serial port baud rate | 9600bps | |
| 14 | LED color | Two-color (white + orange) | |
| 15 | waterproof level | IP67 | |
| 16 | shell material | Zinc alloy | |
| 17 | Operating temperature | -20°C–80°C | |
| 18 | Operating Voltage | DC 9V-32V | |
| 19 | Output Interface | 8 wires | |
| 20 | line length | 45CM | |
| 21 | structure size | 105mm(W)*140mm(H)*52mm | |
| 22 | weight | 709g |
STRUCTURE DIAGRAM
Sound and Light Alarm System
